Name Model EBG-03 Model EBG-06 Model EBG-10
High working pressure Bar (psi) 250 (3600) 250 (3600)
Heavy Flow litre/min (gpm) 100(26.4) 200(52.8) 400(106)
Minor flow litre/min (gpm) 3(.79) 3(.79) 3(.79)
Pressure adjustment range Bar (psi) Refer to "Model Description"
Rated current mA C:770
H:820 C:750
H:800 C:730
H:780
Coil resistance Ω 10 10 10
Hysteresis less than 2% less than 2% less than 2%
Repeat accuracy 1% 1% 1%
Weight kg(lbs) 5.6 (12.3) 6.3 (13.9) 10 (22)
