3 phase asynchronous motor (power range 0.75 to 800 kW) Frequency converter for variable torque applications Series Description
3 phase 200/240 V-380/480 V-500/690 V
UL Type 1/IP20, ranging from 0.75 to 800 kW
UL Type 12/IP54, ranging from 0.75 to 800 kW
Speed range: 1:100 in open loop mode
Overload: 110%... 120% - 60 s
Graphical terminal: plain text, navigation buttons, and an instant "Easy Start" menu that benefits from all of the ATV61's capabilities right away
Integrate Class A or Class B EMC filters
Energy saving method, secondary motor control method
Comply with international standards and certification: CE,UL,CSA,C-Tick
Integrated Modbus and CANopen
Communication cards for industry: Ethernet,FIPIO,Modus Plus,DeviceNet, Interbus-S,Unitelway; Communication cards for buildings: LonWorks,BACnet,me-taSYS N2 and Apogee FLN
I/O expansion card
Programmable multi-pump card: ATV38 compatibility with new application software
PowerSuite software: Configure, set, and save parameters from applications
Economical design
More than 150 features are available
Protect motor and frequency converter
Safety Feature: "Power off",ATEX
Warranty period: 18 months
