Viscosity - Low 33 SSU (2.0 CST). Type B: Large 3000 SSU (650 CST) (consider cold start). Type H: Viscosity above 3000 SSU (650 CST).
Temperature - Type B: 0 to 180°F (-18 to 82°C). Type H: 0 to 250°F (-18 to 121°C) at 1800 RPM or lower, 0 to 225°F (-18 to 107°C) above 1800 RPM.
Drive - direct, belt or chain. Also available in unsealed magnetic drive configuration.
Rotary - clockwise facing pump shaft standard. Counterclockwise consulting Imo
Mount - Can be mounted on the foot in any direction. Flange mounting can be installed horizontally or vertically.
Filtration - An inlet filter is required to prevent contaminants and abrasives from entering the pump. They must be selected in consultation with the filter supplier to prevent pump insufficiency. In general, it is recommended to use 60 mesh (0.01 inch to 238 microns) for light oils and 1/8 to 3/16 inch (3-5 mm) for heavy oils.
High Speed - Do not pump residual fuel or crude oil above 1800 RPM due to the presence of abrasives and contaminants.
