ARCA Locator 824 series

 The 824 series positioner operates on a reliable torque balance principle. The pneumatic anchor point standard signal from the pneumatic controller or I/P converter assembly generates a force on the film. This force is balanced with the spring force on the feedback shaft. The resulting force difference drives the gate valve, which is connected to the intake air or atmosphere to control the valve action.
