Total 2.5kW to total 15kW
Voltage range: 208-575V
Large line current: 30 A per circuit
Pipe:
625 inch OD (5/8") (15.9 mm)
065 inch wall (1.7mm)
Total process Tube Length: 130 "(3302 mm) each
316L Stainless Steel (Standard)
Inconel (optional litre)
Passivation or electropolishing (optional litres)
High pressure: 4000 psi (275 bar)
Shell:
NEMA 1 (Universal/Dust Proof)
NEMA 4 (Moisture-Proof)
NEMA 7 (Explosion Proof)
ATEX (explosion proof)
High operating temperature:
NEMA 1 (Dust Proof/Universal) : 662°F (350°C)
NEMA 4 (Moisture-proof) : 572°F (300°C)
NEMA 7 (Explosion-proof) : 482°F (250°C)
ATEX (Explosion-proof) : 482°F (250°C)
The declared temperature applies to the enclosure at 12 o 'clock;
Higher temperatures are possible at the 6 o 'clock position. Please see factory for details.
Sensors and controls:
K or J type thermocouple
Resistance temperature detector (RTD)
Quick action high limit switch
Enclosure mounted thermostat
Available parts:
Rim jacket
Compression fitting
