Axial load at the end of the shaft ≤ 50N axial / ≤ 100N radial
Bearing life ≥ 3.9 x 10+10 RPM
- Speed ≤ 6000 1/min
- Operating temperature ≤ 60°C
Start at 20°C torque 4 Ncm
The angular acceleration is less than 10+4 rad/s squared
The moment of inertia is 5E minus 6 gm squared
Axle diameter 6 mm; 8 mm ; 10 mm ; 12 mm
Flange 36mm; 50 mm ; 85 mm
The mass is about 0.6kg-1.0kg
