Small and light
Various fluids can be controlled.
Wide range of working pressure
Item \ transformation method standard specification
Oil port size PT1/8, 1/4 (G1/8, 1/4, NPT1/8, 1/4)
Fluid compressed air
Working pressure 0~9.0 bar
Instantaneous flow 300 L/min (5 bar) (based on orifice 3 cakes)
The effective cross-sectional area (Cv) 5.5 ㎟ (0.3) (based on orifice 3 cake)
Ambient and fluid temperature 5~50℃
Response time (5bar) less than 30ms
Large operating frequency 3 cycles per second
Rated coil voltage AC220, AC110, AC24(50-60 Hz)/DC24V, DC12V
Allow voltage fluctuation ±10% of rated voltage
F corresponds to coil edge type
Apparent power AC 9VA (60Hz)
Power consumption DC 7W
