It is lubricated and has excellent durability.
Flow rate 700 L/min (5 bar)
There are a variety of options for the push, lock and coil parts of the manual operation section, with a variety of lead lengths.
Item \ Conversion method ST281S/ST281D
Oil port size PT1/8 (G1/8, NPT1/8)
Fluid compressed air
Working pressure 1.5~9.0 bar
Instantaneous flow 700 L/min (5 bar)
Effective cross-sectional area (Cv value) 0.6
Ambient and fluid temperature 5~60℃
Response time (5bar) less than 25ms
Large operating frequency 5 cycles per second
No lubrication required (use ISO VG32# for lubrication)
Manual operation button (standard), rotating rod (optional)
Rated coil voltage AC220, AC110, AC24 (50~60Hz)
Allow voltage fluctuation ±10% of rated voltage
F corresponds to coil edge type
Apparent power AC 3.5VA (60Hz)
Power consumption DC 2.5W
