High frequency continuous operation. (5c/s)
It has a structure that prevents the valve from sticking, so it can operate accurately and steadily in dust and other adverse conditions.
It can be used under vacuum and high pressure, is a universal two - way or three - way valve.
Project standard specification
Oil port size PT1/4 (G1/4, NPT1/4)
Fluid compressed air
Working pressure 0~9.0 bar
Instantaneous flow 400 L/min (5bar)
Effective area (Cv) 7.2 ㎟ (0.4)
Ambient and fluid temperature 5~60℃
Response time (5bar) less than 35ms
Large operating frequency 5 cycles per second
Rated coil voltage AC220, AC110, AC24(50-60 Hz)/DC24V, DC12V
Allow voltage fluctuation ±10% of rated voltage
F corresponds to coil edge type
Apparent power AC 22VA (60Hz)
Power consumption DC 13W
