It is lubricated and has excellent durability.
Large flow, body width 26.5mm, same size
The basic rotary lever type used for manually operated parts
A variety of coil options, beautiful appearance, durable
Item \ Conversion method single/double
Oil port size PT1/4 (G1/4, NPT1/4)
Fluid compressed air
Working pressure 1.5~9.0 bar
Instantaneous flow 2000 L/min (5bar)
The effective cross-sectional area (Cv) 37.0 ㎟ (0.8)
Ambient and fluid temperature 5~60℃
Response time (5bar) less than 35ms
Large operating frequency 5 cycles per second
No lubrication required (use ISO VG32# for lubrication)
Manual operation rotary bar type (standard), button (option)
Rated coil voltage AC220, AC110, AC24(50-60 Hz)/DC24V, DC12V
Allow voltage fluctuation ±10% of rated voltage
F corresponds to coil edge type
Apparent power AC 4.5VA (60Hz)
Power consumption DC 2.5W
