Edge, etc. : F (155°C) -H (180°C) as required.
Winding wire, etc. : H (180°C)
Protection: waterproof IP-65 (EN60529 standard)
Connect the DIN-43650B plug correctly.
Load: Continuous (S.I.) 100% ED
Power consumption (1) : AC 10VA (surge 20VA)
Dc 8W
Voltage tolerance: ±10%
Electric margin: >1000 Mohm
Dielectric strength: >2000 V/1 '
Standard voltage: 12-24-48-110-220 Vac~ 50/60Hz
12-24-48-110-220 volts DC =
Additional voltages are available upon request.
