Key advantages:
Pressure reducer 300/60 bar
Residual pressure device
The pressure regulating valve is protected by a check device
Tests were carried out according to EN 10297
gas type Inert gas
Mandrel material Brass
Handwheel/handhandle material Aluminum
O-ring material EPDM
Seat material Polyamid
Valve body material Brass
Helium leakage rate at high pressure 1 * 10-3 mbar l/sec (He)
Seat diameter is 4 mm 0.15748 Inches
The egress connects to All standards
The entry connects to All standards
Upper operating temperature 65 Celsius 149 Fahrenheit
Operating temperature limit -20 Celsius -4 Fahrenheit
CV 0.21
Maximum working pressure: 300 bar, 4350 PSI
Certification/Certificate TPED
