Key advantages:
Flow zone without spring design, no particle pollution
metal to metal air tightness
Assemble, test and pack in 10 dust-free workshop
Controlled (PC) electrolytic polishing for better corrosion resistance
Provides 2, 3, or 4 port options
Gas types Standard, High and Ultra High Purity, corrosive and non-corrosive gases
Body material Stainless Steel 316L, VAR
Inlet pressure is 50 bar 725 PSI
Outlet pressure is 10 bar 145 PSI
CV 1,2
Operating temperature limit -20 Celsius -4 Fahrenheit
Upper operating temperature 65 Celsius 149 Fahrenheit
Helium leakage rate at high pressure 1 * 10-9 mbar l/sec (He)
