Key advantages:
Using non-bonded diaphragm technology and spherical hand wheel, sensitive and accurate control can be achieved in small space
Complete traceability, dust-free workshop assembly, testing and packaging
Nano electrolytic polishing ensures better corrosion resistance
Excellent response at low pressure
Small overcurrent volume, easy to purge
Specifications:
Gas types Standard, High and Ultra High Purity, corrosive and non-corrosive gases
Body material Stainless Steel 316L, VAR
Outlet pressure 2, 4, 7, 10 bar29 PSI
Inlet pressure 200 bar2900 PSI
Operating temperature limit -20 Celsius-4 Fahrenheit
Upper operating temperature 65 Celsius149 Fahrenheit
CV0, 09
Helium leakage rate at high pressure 1 * 10-9 mbar l/sec (He)
Exit connection me-tal-to-me-tal Face Seal 1/4
Entry connection me-tal-to-me-tal Face Seal 1/4
Purity level 9
Weight 0.7 grams
