Series /CAD nozzle diameter setting pressure (MPa) Filtration accuracy (μm)
AW20K ~ 40K 1/8,1/4,3/8,1/2,3/4 0.05 ~ 0.85 5
AW60K 3/4,1
Special built-in can quickly outlet side air pressure reliable discharge function (built-in check valve: with countercurrent function).
Oil mist separator pressure reducing valve size AWM
Series /CAD nozzle diameter setting pressure (MPa) Filtration accuracy (μm)
AWM20 ~ 40 1/8,1/4,3/8,1/2 0.05 ~ 0.85 0.3
Mist separator pressure reducing valve size AWD
Series /CAD nozzle diameter setting pressure (MPa) Filtration accuracy (μm)
AWD20 ~ 40 1/8,1/4,3/8,1/2 0.05 ~ 0.85 0.01
Modular F.R.L. air assembly element ACG
Composing せ machine series/CAD to take over the aperture setting pressure
(MPa)
Air filter /
Built-in pressure gauge reducing valve /
